Main technical specificationshnical specifications
Hole Diameter:Φ25～Φ130mm
Spindle Motor:3KW 0～50Hz inverter motor
Spindle Speed:250～3000 rev/min Stepless speed regulation
Stroke Motor : 1.5 KW servo motor
Stroke Speed:20～100 beats/min
Stroke length:0～350mm
Feed Motor:0.45KW servo motor
Shutdown brake for spindle and stroke:program control
Oil Pump Motor:0.125KW
Overall Size（L*W*H）:1900×950×1350(mm)
Machine Net Weight:900KG
Power Source:380V 50Hz, three-phase four-wire
